Preparative HPLC/MPLC

- +

ACCQPrep HP150

          The Teledyne ISCO ACCQPrep™ HP150 is designed to be intuitive and easy-touse with all the performance and accuracy of an HPLC system. The system focuses on purification with the highest sample recovery.

Achieve High Performance Liquid Chromatography (HPLC) simply, without compromise.

       With ease of purification in mind, the user-friendly ACCQPrep HP150 eliminates unnecessary and complex method parameters found in many of the HPLC systems in today’s market. Our PeakTrak® software, designed with the user in mind, is the basis for controlling the ACCQPrep HP150. The integrated software, eliminates the need for a stand-alone PC. This results in a more compact unit with a touch screen interface. Software evolves with user needs and updates are always free.



  • Straightforward Complete control of the system on one screen
  • Compact Designed to take up minimal lab space
  • Flexible Add on Teledyne ISCO Automation Modules and other sample injection and detection options for your separation nee

Standard Features:

  • Flow rates from 1 to 150 mL/min allows scouting and Prep methods on one system
  • Operating pressure up to 6,000 psi
  • Choice of UV or UV-Vis plus ELSD and MS options
  • One touch Focused Gradient Generator maximizes purification time and sample recovery

Read more

ACCQ Prep HP150

Read more

Flow Rate Range 1-150 mL/min
Pressure Limit up to 6000 psi (400 bar)
UV and UV-Vis Detection Variable UV 200-400 nm standard, Variable UV-Vis 200-800 nm option
ELSD Detection Integrated Option that can be combined with either UV or UV-Vis
Number of Solvents Binary gradient, 2 solvent, 2x3 solvents (optional), Fixed third solvent modifier (optional)
Gradient Formation High pressure, dual piston reciprocating pumps
Programmable Gradients Linear, step, isocratic
Gradient Linearity +/-1%
Sample Introduction

Injection loop (standard)

Manual (standard)

AutoInjector (optional)

Large sample load pump (optional)

User Interface 15 in touchscreen, internal CPU, Linux Red Hat
Fraction Collector Internal, External Fraction Collection with AutoSampler (Optional)
Dimensions 27.5x14.0x20.0 in (69.9x35.6x50.8 cm)
84.5 pounds (38.2 kg)
Dimention AS 2x2
Autosampler Module
18.9x14.0x19.3 in (48.0x35.6x49.0 cm)
31.1 lbs (14.1 kg)
